Green Drain
Waterless Drain Trap Seal
Waterless Drain Trap Seal
Green Drain™, a globally multi-patented floor drain solution, is the only product on the market that can provide businesses with protection against the spread of contagious pathogens like COVID-19 as they look to reopen
Functions:
Used in the outlet connections of floor drain bodies or the inside of floor drain strainers to seal the opening, preventing odors, sewer gases, insects, and cross-contamination of aerosolized pathogens caused by simplistic installation into openings that vary in size. Green Drain™ will open to allow drainage and immediately close once the water has water has stopped flowing. Green Drain™ can be used in new construction or retrofitted into applications where trap primers have failed or never installed.
Prevents the following from entering up through floor drains:
- Odors and sewer/random gases
- Insects and harmful pathogen spread
Specifications:
Specifications:
Device Sizes:
Device Sizes:
| Model | Pipe Size Inch | Height | L/M | GPM |
|---|---|---|---|---|
| GD1.25 | 1.25” (31-36 mm) | 26 mm | 22.7 | 6.0 |
| GD15 | 1.5” (37.45 mm) | 28 mm | 30.0 | 8.0 |
| GD2 | 2″ (46-55 mm) | 33 mm | 45.4 | 12.0 |
| GD3 | 3″ (68-80 mm) | 51 mm | 128.7 | 34.0 |
| GD35 | 3.5″ (85-94 mm) | 51 mm | 193.0 | 51.0 |
| GD4 | 4″ (95-104 mm) | 51 mm | 276.3 | 73.0 |
| GD5 | 5″ (105-130 mm) | 51 mm | – | – |
| GD6 | 6″ (145-155mm) | 51 mm | – | – |
